MT-TT04
DRAGON
| Quantity: | |
|---|---|
| PDF Export | |
| Specifications:2130*860*610/920mm(±10mm), bed surface size: 1930*620mm. |
| Guardrail length: 1240mm, quardrail height: 510mm, distance from bed surface: 400mm. |
| Functions: Back elevation 0-75°,knee elevation 0-45°,front-back tilt adjustment-15°-15° |
| Features |
| 1. Back elevation system: Controlled by 2 high-quality silent air spring systems, with stronger load-bearing capacity and greater safety. |
| 2. Height elevation system: Uses imported hydraulic elevation system, with more stable quality. |
| 3. Leg elevation system: Controlled by an ABS hand lever, for knee and leg elevation. |
| 4. Bed board: Back part uses 6mm thick expanded polystyrene material, and the back of the bed board is equipped with a X-ray film slot for taking X-rays |
| 5. Guardrai: Uses an integrated inward-swinging S-shaped quardrail,and the guardrail handrails are made of aluminum alloy and 304 stainless steel. |
| 6. Casters: Diameter200mm central sient casters, each wheel can bear a weight of ≥ 120KG; there are central bralking systems at the head and tail of the bed, with one brake for four wheels positioning. |
| 7. Center fifth wheel system: Uses a shock-absorbing fifth wheel, both sides of the bed have control pedals, effectively controlling the forward direction, making the transportation process safer. |
| 8. Chassis: There is an integrated ABS material chassis under the bed, which can hold oxygen cylinders,convenient to use,and the tray can bear a weight of 10KG. |
| 9. Equipped with 304 stainless steel telescopic infusion tube rack, four-pronged design, pneumatic buffer elevation. |
| 10. Standard configuration: 6cm PU waterproof mattress |
| 11. Two side drainage bag hooks. |
| Optional features: weighing function,instrument stand,electric lifting,PP flip-over parallel guardrail |
