OR-OL01
DRAGON
| Quantity: | |
|---|---|
| PDF Export | |
| 1. Adopt imported LED cold light source |
| 2. Independent depth lighting |
| 3. Intelligent LCD touch control |
| 4. Independent control of minimally invasive lighting, deep cavity lighting and ambient light |
| 5. Illumination shadow automatic compensation function |
| 6. Low energy consumption and high energy efficiency |
| 7. Endo model illiumination:10000lux |
| 8. R9function:≥97 |
| 9. R11 function:≥97 special for neuro-sugery |
| 12. Focus size adjusted electrical |
| 13.One-click synchronization function |
| Diameter of lighthead:70cm |
| Illumination at 1m(lux): 160000 |
| Illumination at 1m on Endo mode(lux): 15000 |
| Light field diameter D10(mm): 180±40 electrically adjusted |
| D50(mm):110±35 |
| L1+L2 Depth of illumination(cm): 150 |
| Independent depthlighting(cm):160 |
| Color rendering index(Ra):100≥Ra≥85 |
| Red colorindex R9:≥97 |
| Optional color temperature(K): 6700≥Tc≥3000(Multi-speed adjustable) |
| Number ofLEDs:87 |
| Average bulb life(hours):50000 |
| Heat-to-light ratio(mW/m²Ix):<6 |
| Power supply:110-240 V,50/60HZ |
| Input Power(VA):50VA |
| Ceiling height for installation(cm):270-320 |
| Green color rendering index R11:≥97 |
| 1. Adopt imported LED cold light source |
| 2. Independent depth lighting |
| 3. Intelligent LCD touch control |
| 4. Independent control of minimally invasive lighting, deep cavity lighting and ambient light |
| 5. Illumination shadow automatic compensation function |
| 6. Low energy consumption and high energy efficiency |
| 7. Endo model illiumination:10000lux |
| 8. R9function:≥97 |
| 9. R11 function:≥97 special for neuro-sugery |
| 12. Focus size adjusted electrical |
| 13.One-click synchronization function |
| Diameter of lighthead:70cm |
| Illumination at 1m(lux): 160000 |
| Illumination at 1m on Endo mode(lux): 15000 |
| Light field diameter D10(mm): 180±40 electrically adjusted |
| D50(mm):110±35 |
| L1+L2 Depth of illumination(cm): 150 |
| Independent depthlighting(cm):160 |
| Color rendering index(Ra):100≥Ra≥85 |
| Red colorindex R9:≥97 |
| Optional color temperature(K): 6700≥Tc≥3000(Multi-speed adjustable) |
| Number ofLEDs:87 |
| Average bulb life(hours):50000 |
| Heat-to-light ratio(mW/m²Ix):<6 |
| Power supply:110-240 V,50/60HZ |
| Input Power(VA):50VA |
| Ceiling height for installation(cm):270-320 |
| Green color rendering index R11:≥97 |
