Ceiling Pendant OR-CP05

The Ceiling Pendant is primarily used to enhance surgical processes and safety for the surgical team. It is a multifunctional device platform integrated into the ceiling.
  • OR-CP05

  • DRAGON

Availability:
Quantity:

PDF Export

Function Box Column: 1 unit
Platform: 1 piece
Platform + Drawer: 1 set
Gas Terminals: 6 units
Power Sockets:10 units (220V/10A)
Grounding Terminals: 2 units
Network Interface:1 unit(RJ45)
Infusion Pump Combination Rack: 1 set
Load-bearing Capacity of Single Tray on Tower Body: ≥60KG
Movement Range (Radius)of Horizontal Arm: ≥950mm
Horizontal Rotation Angle of Tower Body:≥340 degrees
Length of Surgical Gas & Electricity Box: ≥950mm
The gas & electricity box is equipped with a drawer, with a load-bearing capacity of ≥20Kg
